Used MG 60 Ton Capacity Conventional Welding Rotators

Photo 1

Photo 2

Photo 3

Photo 4

1 Model MGCR-60
2 Capacity (Loading) 60 Tonnes
3 Capacity (Turning) 90 Tonnes
4 Vessel Size (Min.) 700mm
5 Vessel Size (Max.) 6000mm
6 Tyre Type and Size Polyurethane 520mm x 356mm
7 Electrical Panel Yes
8 Control Means Via Push Button Pendant c/w 10m Cable
9 Incoming Supply 415V-3P-50Hz
10 Roller Drive Motor 2 x 2.2 Kw with force vent cooling
11 Roller Speed 126mm to 1260mm / Min
12 Surface Preparation Gritblast to SA2.5
13 Color Red
15 Width 900mm – Drive. 720mm - Idler
16 Height 765mm
17 Length 4370mm – Drive. 3200mm Idler
18 Weight 1960 Kgs Drive. 1310 Kgs Idler


Category: Welding and Cutting Machinery

Seller's location: West Midlands, UK
To see the seller's contact details please use the contact form below.

The seller confirmed the item was still for sale on: 31 Dec 2021
