Used and new machines recently added

Doosan 280LM CNC Lathe (2007) Doosan 280LM CNC Lathe (2007)
410mm max cutting diameter, 630mm swing, 1030mm max turned length, 76mm bar capacity, 22kW motor, Fanuc Oi-Series Control, 300mm Jaw Chuck, Tool setter, 12 Station turret, spindle speed 3500rpm, swarf conveyor, toolsetter, Tailstock, coolant, parts...
Lathes - CNC
Automatic sheetmetal warehouse tower STIMA ENGINEERING Automatic sheetmetal warehouse tower STIMA ENGINEERING
STIMA ENGINEERING LY-01-471-000 (year 2007) Automatic sheetmetal warehouse (vertical)/ Tower. 29 shelves. In operation. Weight Max. 3000 kg. / Height 85 mm. For metal sheets up to 3000 x 1500. With video
Storage/Stillages
4100mm x 240 Ton CNC Press Brake.  Serial No. B23420.  Manufactured 2016 4100mm x 240 Ton CNC Press Brake. Serial No. B23420. Manufactured 2016
Manufacturer: MORGAN RUSHWORTH Model: PBS 4100/240 [Ref: 33302]
Presses and drop stamps
4 Axis Horizontal Machining Centre.  Tosnuc 8 Control - X,Y,Z & Full B Axis.  Twin Pallet 800mm x 800mm. X = 1600mm, Y = 1250mm.  Z = 1200mm.  With selection of tools and back end tooling 4 Axis Horizontal Machining Centre. Tosnuc 8 Control - X,Y,Z & Full B Axis. Twin Pallet 800mm x 800mm. X = 1600mm, Y = 1250mm. Z = 1200mm. With selection of tools and back end tooling
Manufacturer: TOSHIBA Model: BMC-800 Year of Manufacture: 1996 Control: Tosnuc 8 Pallet size: 2 x 800mm x 800mm, loading capacity 2000 kgs Speeds: 10,000 rpm Automatic tool changer: 60 ATC Input: 30 kW main motor [Ref: J33291]
Machining centres
KINGSLAND COMPACT 40 HYDRAULIC STEELWORKER KINGSLAND COMPACT 40 HYDRAULIC STEELWORKER
40 tons, punch 38 thru 8mm/20 thru 15mm, shear 200 x 13mm/350 x 6mm, Angle 80 x 80 x 8mm, Motor 3kw, length stop, tooling, light
Ironworkers
36 Gear Shaper.  With Cabinet of Change Gears.  Manufactured 1983 36" Gear Shaper. With Cabinet of Change Gears. Manufactured 1983
Manufacturer: TOS Model: OHO50 [Ref: J33286]
Misc
Broadbent Deep Hole Borer x 10,000mm Broadbent Deep Hole Borer x 10,000mm
Hollow spindle headstock 15” Headstock speeds 11.5 -350 rpm Headstock drive motor Centre height over bed 22” 32” dia 4 jaw chuck on headstock Overall length of bed 85` Max boring length in one pass approx. 32`(10,000mm) Boring saddle with...
Boring - deep hole
Universal Ironworker.  Serial No. 976598, with Tooling Universal Ironworker. Serial No. 976598, with Tooling
Manufacturer: KINGSLAND Model: 45XA [Ref: 33306]
Milling
Amada GS 630 Guillotine Amada GS 630 Guillotine
3050mm x 6.5mm 60 spm Numerical Control operated back stops Back gauge 1000mm Blade angle 0-1.20 Cutting angle & blade gape adjustment Automatic Hydraulic hold downs Stroke limitation automatic Single stroking or continuous automatic ...
Sheet metal-working
SPINNER VC 1020 VERTICAL MACHINING CENTRE SPINNER VC 1020 VERTICAL MACHINING CENTRE
MAKE: SPINNER MODEL: VC 1020 YEAR: 2006 CONTROL: FANUC 0i-MC TABLE SIZE: 1200 x 610 mm TABLE LOAD: 1000 KGS TRAVERSES (XYZ): X AXIS: 1020 mm Y AXIS: 610 Z AXIS: 610 SPINDLE SPEED: 8000 rpm SPINDLE TAPER: ISO 40 ATC: 24 STATIONS
Machining centres
Icaro Bar Benders Cutters Icaro Bar Benders Cutters
Italian Manufacture Icaro Produce high quality industrial solid bar bending machines with capacity up to 70mm OD. We are the Sole UK Stockist and keep a selection of machines in stock Benders, Cutters and Combi Models. They also manufacture bar...
Bar & Tube
BRIDGEPORT INTERACT 1 MK. 2 CNC VERTICAL MILL BRIDGEPORT INTERACT 1 MK. 2 CNC VERTICAL MILL
BRIDGEPORT INTERACT 1 MK. 2 CNC VERTICAL MILL Spindle BT30 Quick Change : Table 860 x 320mm : Traverses X - 457 x Y - 305 x Z - 127mm : Programmable Speeds 40 - 4000 rpm : Heidenhain TNC 370 3 Axis CNC Control : Selection of Tooling : Coolant : Low...
Milling - NC/CNC
Contur H660-A CNC Lathe Contur H660-A CNC Lathe
German built Fanuc 21iT controlled Contur H660-A Heavy Duty CNC / Manual flatbed centre lathe, supplied with an 8 position automatic tool post, additional heavy duty drilling attachment, tailstock, coolant equipment and swarf conveyor, 300mm 3 jaw...
Lathes - CNC
Colchester Triumph 2000 - Fully Refurbished Colchester Triumph 2000 - Fully Refurbished

Lathes - general
Ring Section Roller Tube Roller Tooling In Stock Ring Section Roller Tube Roller Tooling In Stock
We stock Tooling to suit Ring Rolling Machines with 40 & 50mm Shafts Sizes In Stock for 40 - 50 shafts 1" OD 25.4mm 1 1/4" OD 31.75 1 1/2" OD 38.1mm 1 3/4" OD 44.45mm 2" OD 1" NB 33.7mm 1 1/4" NB 42.4mm 1 1/2" NB 48.3mm 2" NB...
Ring Rollers
Tornos 6250-C Ex-University Heavy Duty Lathe Tornos 6250-C Ex-University Heavy Duty Lathe
Ex University Tornos 6250-C manual gap bed heavy duty centre lathe equipped with 2 axis DRO 300mm 3 jaw chuck, 400mm 4 jaw chuck, 600mm faceplate, quick change toolpost & holders, In immaculate condition. Specification: Max. swing dia. over bed –...
Lathes - general
Used VOORTMAN Steel Fabrication Machinery Used VOORTMAN Steel Fabrication Machinery
V603/VB1050 Saw/Drill (2007) V630/VB1050 Saw/Drill (2005) V704 Scribing (2012) V808 Robot Cope (2011) V550‐6 Punch/Shear (2015)
Sawing - metal
Mazak HCN4000 - SmoothG Horizontal Machining Centre (9580) Mazak HCN4000 - SmoothG Horizontal Machining Centre (9580)
Mazak HCN4000 - SmoothG Horizontal Machining Centre, 2017, s/n279321, Twin Pallet, Full 4th axis 360,000 degree, Edge locators on pallet, travel X-560, Y-640, Z-640mm, tooling CAT40, 18,000RPM, Rapid movement 60m/min, pallet size 400 x 400mm, 120...
Machining centres
ANDMAR 1224 Surface Grinding Machine (2005) ANDMAR 1224 Surface Grinding Machine (2005)
12in x 24in capacity, 12in x 24in electro-magnetic chuck, auto downfeed, dressing, coolant filtration.
Grinding
WARD 7E Big Bore Lathe WARD 7E Big Bore Lathe

Lathes - general
