2005 Mazak Integrex 300-III ST CNC mill-turn center

Photo 1

Photo 2

Photo 3

Photo 4

X1/X2-axis travel: 630/230mm
Y-axis travel: 230mm
Z1/Z2-axis travel: 1585/1530mm
W-axis travel: 1530mm
X1/X2/Y/Z1/Z2/W-axis rapid traverse: 38/38/26/38/38/30 m/min
Maximum working length: 1524mm
Maximum working diameter: 760mm
Main spindle speed: 35-4.000 rpm
Sub spindle speed: 35-4.000 rpm
Main/sub spindle bore: 88mm
Main/sub spindle power: 26 kW
Milling spindle speed: 15-12.000 rpm
Milling spindle power: 18,5 kW
Toolholder type: C6
Positions in the toolmagazine: 80
Positions on turret: 9
Control system: Mazatrol 640MT Pro
Equipped with: un-loading magazine, tool pre setter, Mayfran chip conveyor, paper filter, wetter oil mist separator, probe, 2x Forkardt 250mm 3-jaw chuck, various jaw sets, 260x C6 toolholder

Machine available from site in Switzerland

Category: Public Auction

Seller's location: Netherlands
To see the seller's contact details please use the contact form below.

The seller confirmed the item was still for sale on: 14 Apr 2025
