Alzmetall GS 1000/5-T 5 Axis CNC Machining Centre (2014)

Photo 1

Photo 2

Photo 3

Photo 4

5 axis
X-Axis 800 mm
Y-Axis 800 mm
Z-Axis 600 mm
Interference circle diameter 1070 mm
Distance Spindle Up to 823,5 mm
Machine-Table Load 1000 Kg
Maximum rapid travel X/Y/Z at TCP max 75 m/min
Cutting-Tool Interface HSK-A63
Motor-Spindle-Power at CDF 25% max 50kW
Motor-Spindle Torque at CDF 25% max 187 Nm
Machine weight 13000 kgs
Wiring diagram: 2526-95-64934955

Resy Filtration system
Model : 14-P00449-3
Serial : KBF- 452/500

Erowa pallet changer
Model RobotEasy
Serial number ERE1364
Year 2014
Weight 1300kgs

Hyfra Pedia chillers
Model sigma 7-s
Please note lot located in Eschenlohe

Located in Eschenlohe & Putzbrunn, Germany
