Harrison M390 Gap Bed Centre Lathe

Photo 1

Photo 2

Photo 3

Photo 4

Harrison

Model
M390 Gap Bed Centre Lathe

Distance between centres
50” (1270mm)

Swing over bed
15.7” (390mm)

Swing in gap
23” (585mm)

Swing over cross slide
9.7” (245mm)

Spindle nose
D1-6” Camlock

Spindle Bore
2” (53mm)

Speeds
16: 25-2000 RPM

Tailstock Spindle Taper
5 Morse

Equipment
3 Jaw Chuck
4 Way Tool Post
Foot Brake
Coolant
Analam DRO – SINGLE AXIS – Y (no warranty on used digital read out systems)

Motor Size
5.5 kW / 7.4 Horse Power 11.3 amps max load

Power
Three Phase Electric's

Category: Lathes - general

Seller's location: Co Durham, UK
