Anayak HVM 7000 Travelling Column Milling Machine

Photo of machine

Photo 1

Photo of machine

Photo 2

Photo of machine

Photo 3

Photo of machine

Photo 4

Photo of machine

Year of Manufacture :1998
CNC :HEIDENHAIN TNC 426

Table Surface: :7.100 X 1.200 mm
Longitudinal Traverse (X Axis) :7.000 mm
Transversal Traverse (Y Axis) :1.100 mm
Vertical Traverse (Z Axis) :1.800 mm
Rapid Traverse :20.000 mm/min
Max. Working Feed :10.000 mm/min
Automatic Head 2.5º / 2,5º :INCLUDED
Taper: :SK-50
Turning Speeds: :20 - 3.000 r.p.m.
Speed Ranges : 2
Main Motor Power :50 Kw
ATC :INCLUDED
Positions at ATC :40
Internal Coolant :INCLUDED
Chip Conveyor :INCLUDED
2 Rotary Table :1200x1200 mm
Portable Handwheel :INCLUDED
Touchprobe :INCLUDED
Paper Filter- additional tank :INCLUDED
Double Operator Control Panel :INCLUDED
Operator platform :INCLUDED
4 Sliding Door Portections :INCLUDED
Max. Carrying Load Table: :30.000 Kg.
Max. Weight Allowed on Spirsin Rotary Table :5.000 Kg.
Machine Weight: :45.000 Kg.


Category: Milling - CNC 4th Axis

Seller's location: Spain
