2016 Mikron HPM 450 U

Photo 1

Photo 2

Photo 3

Photo 4

5-axis Multi-Pallet Machining Centre

Heidenhain iTNC 530
Table size ø 450 mm (Radial T-slots)
Max weight on table 150 kg
X/Y/Z Axis Travels 600/450/450 mm
B-Axis -120°/+45°
C-axis 360° x 0.001°
Rapids B 50 rpm
Rapids C 140 rpm
Machine with EC conformity declaration
Scratchproof windows
Complete machine enclosure
Spindle 20000 min-¹/ HPC 190/ HSK-A63
Tool magazine 120× HSK-A63
Rotary/ tilt table NG Dynafix
Pallet magazine 7× Dynafix
Preparation Touch Probe M&H
Touch Probe M&H 40.01
Rotating window
Lateral Chip Conveyor
Lift up scraper type chip conveyor
Band filter system 650l ARO
Through spindle coolant 15-40 bar
Compressed air blow off external
Beacon
Blum Laser measuring system
APS Advanced Process System
ITC Intelligent Thermal Control
ITC-5X Intelligent Thermal Control 5-Axis
KinematicsOpt
Handwheel

* * * ex Formula 1 subcontractor, ca 17500 run hours * * *





Category: Machining centres

Seller's location: Surrey, UK
To see the seller's contact details please use the contact form below.

The seller confirmed the item was still for sale on: 21 Dec 2020
